How to plumb a two line wet kit is a common question among truck owners and operators who need hydraulic power for dump trailers, walking floors, live bottoms, or other hydraulic equipment. A two line wet kit is a hydraulic system installed on a truck tractor that supplies pressurized hydraulic fluid to a trailer. It typically consists of a pressure line and a return line, along with a hydraulic pump, reservoir, control valve, and associated fittings and hoses. Proper plumbing of the system is critical to ensure safe operation, long component life, and reliable hydraulic performance.

A two line wet kit differs from a three line system in that it uses one pressure line and one return line between the truck and trailer. In contrast, a three line system adds a dedicated case drain line for certain high-performance applications. Understanding how the two line configuration works is essential before beginning installation.

Understanding the Components of a Two Line Wet Kit

Before plumbing the system, it is important to understand each major component and its function. The hydraulic pump is typically mounted to the truck’s transmission using a power take-off unit. The power take-off transfers mechanical energy from the transmission to drive the pump. The pump then draws hydraulic fluid from the reservoir and sends it under pressure through the system.

The hydraulic reservoir stores the fluid and allows it to cool and de-aerate before recirculation. The control valve regulates fluid flow to the pressure line and directs returning fluid back to the tank. The pressure hose carries high-pressure fluid to the trailer, while the return hose carries used fluid back to the reservoir.

Quick couplers are mounted at the rear of the truck to allow fast connection and disconnection between tractor and trailer. These couplers must be rated for the operating pressure of the system.

Planning the Installation

Proper planning is the first step in how to plumb a two line wet kit. The installer must determine where the hydraulic tank will be mounted, usually on the truck frame rail. Space constraints, exhaust routing, and clearance from suspension components must all be considered.

The pump location depends on the transmission type and the power take-off configuration. Confirm compatibility between the transmission and the PTO unit before installation.

Hose routing must be carefully planned to avoid sharp bends, excessive heat sources, and moving components such as drive shafts or suspension parts. Secure mounting points for clamps and brackets should be identified in advance.

Installing the Hydraulic Reservoir

The reservoir is typically mounted on the side of the truck frame. Use heavy-duty brackets designed to support the weight of the tank when filled with hydraulic fluid. Ensure the mounting hardware is tightened according to manufacturer specifications.

The suction port at the bottom of the tank connects to the inlet of the hydraulic pump. This line must be large enough in diameter to prevent cavitation. Cavitation occurs when the pump does not receive adequate fluid supply, causing air bubbles and potential pump damage.

Install a suction hose rated for hydraulic service. Avoid restrictions in this line, and ensure fittings are properly sealed to prevent air leaks.

Installing the PTO and Hydraulic Pump

After mounting the PTO to the transmission, attach the hydraulic pump securely. The pump inlet connects to the suction line from the reservoir. The outlet of the pump connects to the control valve through a high-pressure hose.

Ensure all fittings are properly torqued. Use thread sealant where recommended, but avoid excessive use that could contaminate the hydraulic system.

Check alignment between the PTO and pump to prevent premature wear. After installation, verify that the PTO engages and disengages smoothly.

Plumbing the Pressure Line

The pressure line carries high-pressure fluid from the control valve to the trailer. This hose must be rated for the maximum operating pressure of the system.

Connect the pump outlet to the inlet port of the control valve. From the valve’s pressure output port, route a hose to the rear of the truck where quick couplers are mounted.

Secure the hose along the truck frame using clamps spaced at regular intervals. Avoid routing near hot exhaust components unless protective heat shielding is used.

At the rear, connect the hose to the pressure-side quick coupler. Labeling the coupler clearly helps prevent incorrect connections.

Plumbing the Return Line

The return line carries fluid back from the trailer to the reservoir. In a two line wet kit, this line is separate from the pressure line and typically enters the tank at a designated return port.

From the rear quick coupler, route the return hose forward along the frame. Connect it to the return port on the control valve or directly to the tank, depending on system design.

Ensure the return line has sufficient diameter to allow unrestricted flow. A restricted return line can cause overheating and increased back pressure.

Install a return line filter if specified by the system manufacturer. This filter removes contaminants before fluid re-enters the tank.

Installing Quick Couplers

Quick couplers are essential for connecting and disconnecting the trailer. Mount them securely to a bracket at the rear of the truck, typically near the frame cross member.

Ensure the pressure and return couplers are clearly marked. Connecting hoses incorrectly can damage hydraulic components.

Check that couplers are compatible with the trailer’s fittings. Standardizing coupler types across equipment reduces confusion and connection issues.

Filling and Priming the System

After plumbing is complete, fill the reservoir with the recommended hydraulic fluid. Consult manufacturer specifications for correct fluid type and viscosity.

Before operating under load, prime the system. Engage the PTO briefly to allow fluid to circulate. Check for leaks at all connections.

Monitor fluid level and add more if necessary. Air trapped in the system may cause temporary noise or jerky operation until fully purged.

Testing the System

Testing is a critical step in how to plumb a two line wet kit. With the trailer connected, engage the PTO and operate the hydraulic equipment slowly.

Observe pressure readings if a gauge is installed. Verify smooth operation and proper function of the control valve.

Check for leaks along hoses and fittings. Even small leaks should be addressed immediately to prevent larger failures.

Monitor fluid temperature during extended operation. Excessive heat may indicate restricted flow or improper hose sizing.

Safety Considerations

Hydraulic systems operate under high pressure and can be dangerous if improperly installed. Always relieve system pressure before disconnecting hoses.

Wear protective gloves and eye protection when working with hydraulic components. High-pressure fluid injection injuries can be severe.

Ensure all hoses are rated for hydraulic service and operating pressure. Never substitute with lower-rated hoses.

Keep hands and clothing away from moving parts when engaging the PTO.

Maintenance After Installation

Regular maintenance ensures long-term reliability. Inspect hoses periodically for signs of wear, cracking, or abrasion.

Check fluid levels routinely and replace filters according to manufacturer recommendations.

Tighten mounting hardware as needed and ensure clamps remain secure.

Keeping the system clean prevents contamination and extends component life.

Common Mistakes to Avoid

One common mistake is using undersized hoses. This restricts flow and increases system heat.

Another mistake is improper hose routing near sharp edges or moving components, leading to premature hose failure.

Failure to properly secure hoses can result in vibration damage.

Incorrectly connecting pressure and return lines at the couplers can cause system malfunction.

Two Line Versus Three Line Systems

Understanding system requirements is important when considering how to plumb a two line wet kit. Two line systems are suitable for many dump and walking floor applications. However, some high-performance hydraulic motors require a dedicated case drain line, which would require a three line setup.

Selecting the correct system configuration ensures compatibility with the intended trailer equipment.

Final Thoughts

Learning how to plumb a two line wet kit requires careful planning, proper component selection, and attention to detail. From mounting the reservoir and pump to routing pressure and return lines, each step plays a critical role in system performance.

By following structured installation procedures, securing hoses properly, verifying connections, and conducting thorough testing, operators can achieve a safe and efficient hydraulic setup. A properly plumbed two line wet kit provides reliable hydraulic power for demanding trailer applications while ensuring durability and long service life.
